7インチTFT LCDモジュール

The 7 inch TFT LCD module is the ideal solution for anyone looking for an affordable and reliable display module that delivers high-quality performance. With a robust design, a range of features, and compatibility with a range of interfaces, this module is sure to meet all your display needs. Contact us today to learn more about this innovative product and how it can benefit your business.

Screen Size: CNKT0700-19049A1
LCD Size: 7.0 inches diagonal
Number of Pixel: 1024 RGB (H) ×600(V) pixel
Display area: 154.2144(H) x 85.92(V)mm
Outline Dimension: 165.0 x 100x3.5(Typ) mm
Display mode: Normally white, TN
Pixel arrangement: RGB Vertical stripe
Pixel pitch: 0.1506(H)x0.1432(V)mm
Back-light: LED Side-light type
Surface treatment: Antiglare, Hard-Coating (3H)
Interface: RGB

With a resolution of 800 x 480, our 7 inch TFT LCD module provides a sharp and clear display that is perfect for a wide range of applications. Whether you're using it for gaming, industrial use, medical equipment, or vehicle displays, this module delivers a vivid and colorful image that is sure to grab your attention.

The module features a high brightness of up to 1000 cd/m², making it ideal for outdoor use or environments that are brightly lit. In addition, this TFT LCD module is built to last, with a lifespan of over 50,000 hours, ensuring that you won't have to worry about replacing it for a long time.

Our module also includes a built-in resistive touch screen that is highly responsive and accurate, providing a seamless user experience. With multiple touch points, this module is perfect for touch-based applications such as kiosks, ATMs, and point-of-sale displays.

The 7 inch TFT LCD module is easy to install and operate, making it accessible to anyone without the need for extensive technical knowledge or expertise. The module comes with a user-friendly interface that can be easily configured to suit your needs, and it is fully compatible with a range of interfaces including HDMI, VGA, and AV.
